COMP Cams CL11-607-5 Magnum Marine 280/286 Solid Flat Cam and Lifter Kit Chevrolet Big Block 396-454
by COMP Cams
SKU ds_BDQQ_CL11-607-5
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$672.17
-
Original price
$672.17
Original price
$672.17
$672.17
$672.17
-
$672.17
Current price
$672.17
Availability:
Out of stock
Description
CL-KIT - Cam and Lifter Kit Includes: Camshaft, Lifters, Assembly Lube, Decals and Instructions.
Resources
Installation InstructionsResources
Installation InstructionsSpecifications
| Advertised Exhaust Duration | 324 |
| Advertised Intake Duration | 320 |
| Amazon ASIN | B001GESFLK |
| Assembly Lubricant Included | Yes |
| Basic Operating RPM Range | 4,500-7500 |
| C.A.R.B. E.O. Number | N/A |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for On-Road Vehicles? | No |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles? | Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exemption Reason | N/A |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Cam Type | Solid Flat Tappet |
| Camshaft Gear Attachment | 3-Bolt |
| Camshaft Material | Cast Iron |
| Camshaft Series | Magnum Marine |
| Description_ASM | Chevrolet GEN IV 396-454 Big Block Engines Originally Equipped with Flat Tappet Camshafts |
| Description_DEF | Engine Camshaft and Lifter Kit |
| Description_DES | Magnum Marine 280/286 Solid Flat Cam and Lifter Kit Chevrolet Big Block 396-454 |
| Description_DES | Magnum Marine 280/286 Solid Flat Cam for Chevrolet Big Block 396-454 |
| Description_DES | Solid Lifter Set for Cadillac 472-500 and Chevrolet. |
| Description_EXT | For use in large engine. Flat or hydro. Use tunnel ram. 11.5:1+ compression. |
| Description_INV | MMarine 280/286 S-Flt CL-Kit BBC 396-454 |
| Description_KEY | Chevelle, Camaro, Corvette, Stingray, Silverado, C10, Firebird, Chevrolet, Big Block, Chevy, BBC, 454, 427, 502, 396, Caprice, Malibu, Impala, Nova, Monte Carlo, S10, 572 |
| Description_MKT | CL-KIT - Cam and Lifter Kit Includes: Camshaft, Lifters, Assembly Lube, Decals and Instructions. |
| Description_SHO | Camshaft, Lifter Kt |
| Description_SHP | None |
| Engine Family | Chevrolet 396-454 c.i. 8 Cylinder (1967-1996) |
| Exhaust Duration at .050 inch Lift | 286 |
| Exhaust Valve Lift | 0.656 |
| Gaskets Included | No |
| height | 3.0 |
| Intake Duration at .050 Inch Lift | 280 |
| Intake Valve Lift | 0.638 |
| Kit Type | CL-Kit - Cam and Lifter Kit |
| length | 25.5 |
| Lifter Type | Solid Flat Tappet |
| Lifters Included | Yes |
| Lobe Separation | 110 |
| Locks Included | No |
| LTL | N |
| Retainers Included | No |
| Timing Chain and Gears Included | No |
| Title | Magnum Marine 280/286 Solid Flat Cam and Lifter Kit Chevrolet Big Block 396-454 |
| Usage | Marine |
| Valve Springs Required | Yes |
| Valve Stem Seals Included | No |
| weight | 15.0 |
| width | 5.5 |
