COMP Cams 35-430-8 Magnum 224/224 Hydraulic Roller Cam for Ford 5.0L
by COMP Cams
SKU ds_BDQQ_35-430-8
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Original price
$869.74
-
Original price
$869.74
Original price
$869.74
$869.74
$869.74
-
$869.74
Current price
$869.74
Availability:
Only 1 left!
Description
Street machine and limited high performance street use. Best with 5 speed or 2200-2500 stall. 3.40 to 4.10 gears, aftermarket intake and headers.
Resources
Installation InstructionsResources
Installation InstructionsSpecifications
| Advertised Exhaust Duration | 280 |
| Advertised Intake Duration | 280 |
| Amazon ASIN | B000P5BB5I |
| Assembly Lubricant Included | No |
| Basic Operating RPM Range | 2,500-6,000 |
| C.A.R.B. E.O. Number | N/A |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for On-Road Vehicles? | No |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles? | Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exemption Reason | N/A |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Cam and Lifter Kit Upgrade | CL35-430-8 |
| Cam Type | Hydraulic Roller |
| Camshaft Gear Attachment | 1-Bolt |
| Camshaft Material | Austempered Ductile Iron |
| Camshaft Series | Magnum |
| Description_ASM | Fits Ford 5.0 and 351W w/ factory roller camshafts |
| Description_DEF | Engine Camshaft |
| Description_DES | Magnum 224/224 Hydraulic Roller Cam for Ford 5.0L |
| Description_EXT | Street machine and limited high performance street use. Best with 5 speed or 2200-2500 stall. 3.40 to 4.10 gears, aftermarket intake and headers. |
| Description_INV | Magnum 224/224 Hyd Roller Cam Ford 5.0L |
| Description_KEY | 22 |
| Description_KEY | 260 |
| Description_KEY | 289 |
| Description_KEY | 302 |
| Description_KEY | 308 |
| Description_KEY | 351 |
| Description_KEY | 5.0 |
| Description_KEY | Boss |
| Description_KEY | Cougar |
| Description_KEY | F-150 |
| Description_KEY | Fairlane |
| Description_KEY | Ford |
| Description_KEY | Galaxie |
| Description_KEY | Grand Marquis |
| Description_KEY | GT |
| Description_KEY | GT-350 |
| Description_KEY | HiPo |
| Description_KEY | K-Code |
| Description_KEY | LTD |
| Description_KEY | Mercury |
| Description_KEY | Meteor |
| Description_KEY | Mustang |
| Description_KEY | SBF |
| Description_KEY | Shelby |
| Description_KEY | Squire |
| Description_KEY | Sunbeam |
| Description_KEY | Thunderbird |
| Description_KEY | Tiger |
| Description_KEY | Torino |
| Description_KEY | Windsor |
| Description_SHO | Mag224/224HRlrFrd5.0 |
| Description_SHP | None |
| Engine Family | Ford 5.0L (1985-2002) |
| Exhaust Duration at .050 inch Lift | 224 |
| Exhaust Valve Lift | 0.56 |
| Grind Number | 280HR |
| height | 2.6 |
| Intake Duration at .050 Inch Lift | 224 |
| Intake Valve Lift | 0.56 |
| K-Kit Upgrade | K35-430-8 |
| length | 24.2 |
| Lifter Type | Hydraulic Roller |
| Lifters Included | No |
| Lobe Separation | 110 |
| LTL | N |
| SK-Kit Upgrade | SK35-430-8 |
| Title | Magnum 224/224 Hydraulic Roller Cam for Ford 5.0L |
| Usage | Street/Strip |
| Valve Springs Required | Yes |
| weight | 9.65 |
| width | 2.9 |
