G2 Axle and Gear 67-2051JKFLRH Differential Housing
SKU ds_FCNB_67-2051JKFLRH
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$5,483.22
-
Original price
$5,483.22
Original price
$5,483.22
$5,483.22
$5,483.22
-
$5,483.22
Current price
$5,483.22
Availability:
Out of stock
Description
American-made Core 44 housings accept the latest generation Dana 44 gear design, with a larger diameter ring gear and bigger pinion shaft to withstand hard off-road use. Housings feature forged bearing caps and a unique G-lock adjuster nut system to set backlash and carrier bearing preload. Core 44 axles use additional ribbing on the cast center section and 3-inch diameter, 5/16-wall DOM axle tubes with forged inner Cs for use with tall, aggressive tires. The Core 44 is a direct replacement for the Dana 30 under the front of your leaf sprung 87-95 YJ Wrangler or coil sprung 97-06 TJ Wrangler. All brackets are designed around stock mounting points, and are laser cut and CNC formed from 3/8-inch steel for added strength. Company also gusseted and reinforced any weak points to prevent damage to the brackets and finish the housing in a UV-stable black powdercoat.
Specifications
| Axle Type | Dana 44 |
| Description_DEF | Drive Shaft |
| Description_DES | CORE 44 Axle Housing |
| Description_DES | Core 44 Metric Housing Added Caster 4In-Up Lift |
| Description_EXT | CORE 44 Axle Housing; Front Bolt In Replacement; High Pinion; Added Caster For 4 in. And Higher Lift Kit; Uses Metric Carrier Bearings; Right Hand Drive; |
| Description_FAB | 07-Current Wrangler JK, 2 & 4 Door |
| Description_FAB | Heavy Duty Forged Bearing Caps |
| Description_FAB | Massive Forged Inner C Ends |
| Description_FAB | Spanner Nuts For Backlash Adjustment |
| Description_INV | CORE 44 METRIC HOUSING |
| Description_LAB | Made In Logo |
| Description_LAB | Proposition 65 |
| Description_MKT | American-made Core 44 housings accept the latest generation Dana 44 gear design, with a larger diameter ring gear and bigger pinion shaft to withstand hard off-road use. Housings feature forged bearing caps and a unique G-lock adjuster nut system to set backlash and carrier bearing preload. Core 44 axles use additional ribbing on the cast center section and 3-inch diameter, 5/16-wall DOM axle tubes with forged inner Cs for use with tall, aggressive tires. The Core 44 is a direct replacement for the Dana 30 under the front of your leaf sprung 87-95 YJ Wrangler or coil sprung 97-06 TJ Wrangler. All brackets are designed around stock mounting points, and are laser cut and CNC formed from 3/8-inch steel for added strength. Company also gusseted and reinforced any weak points to prevent damage to the brackets and finish the housing in a UV-stable black powdercoat. |
| Description_SHO | Differential Housing |
| Differential Case Design Type | Dana 44 |
| Hardware Included | Yes |
| height | 20.0 |
| length | 78.0 |
| LTL | N |
| Position | Rear |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
| weight | 224.0 |
| width | 24.0 |
