FAST 303001 XFI Sportsman EFI Kit with 4150 Throttle Body
by FAST
SKU ds_DXKP_303001
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$4,064.61
-
Original price
$4,064.61
Original price
$4,064.61
$4,064.61
$4,064.61
-
$4,064.61
Current price
$4,064.61
Availability:
Out of stock
Description
most users will use Speed Density but the Alpha-N option is specifically added to serve sportsman drag racers looking for absolute consistency. The FAST XFI Sportsman System features full tables to monitor fueling, acceleration fuel, timing and air/fuel targets, while full function data logging is also included. It supports both naturally aspirated and boosted applications up to 5 BAR, is compatible with wet nitrous and has nitrous timing retard control. Built-in CAN network support for the EZ-TCU, EZ-LS and XIM means users can easily plug-and-play those components with the included CAN wire. The FAST XFI Sportsman Engine Management System also features a Bosch wide-band 02 sensor, utilizes built-in diagnostic LEDs, a waterproof ECU enclosure and includes a premium, mesh-type, wire loom multi-port harness. Compatible with return-style and returnless fuel systems, XFI Sportsman is designed for use with high-impedance injectors and works with a variety of multi-port systems or either generation of the FAST EZ-EFI throttle body. XFI Sportsman is conveniently configurable to work with FAST distributors, FAST crank triggers, EZ-LS, XIM or the RPM/tach signal from an aftermarket CD ignition box, HEI big cap distributor or included tach adapter.
Resources
Installation InstructionsResources
Installation InstructionsSpecifications
| Able to Control Boost? | No |
| Able to control ignition timing? | Yes |
| Boost Compatible? | Yes |
| C.A.R.B. EO Number | N/A |
| C.A.R.B. Exempt? | No |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Can Support Internal Datalogging? | Yes |
| Compatible w/ E85 Fuel | Yes |
| Compatible w/ Returnless Fuel System? | Yes |
| Description_DEF | Fuel Injection System |
| Description_DES | 3/8 ID Split Braid Wire Loom |
| Description_DES | 4150 TBI Style Throttle Body |
| Description_DES | 8 SAE O-Ring to 6AN |
| Description_DES | Billet Sensor Block for 30425 Fuel Pressure Sensor |
| Description_DES | Billet Spacer for 30425 Fuel Sensor |
| Description_DES | Bosch LSU4 Wideband Oxygen Sensor |
| Description_DES | Brass Adapter Bushing for Coolant Temperature Sensor |
| Description_DES | Coolant Temperature Sensor |
| Description_DES | EZ 2.0 to MSD Crank Adapter |
| Description_DES | EZ-EFI Fuel + Ignition/2.0 Main Harness |
| Description_DES | Fuel Pressure Sensor for EZ-EFI Fuel+Ignition |
| Description_DES | O2 Sensor Bung Plug |
| Description_DES | Tachometer Adapter/RPM Module for FAST EZ Fuel and EZ Fuel + Ignition |
| Description_DES | Weld-In Oxygen Sensor Bung |
| Description_DES | XFI Chrome Badge |
| Description_DES | XFI Sportsman ECU |
| Description_DES | XFI Sportsman EFI Kit with 4150 Throttle Body |
| Description_EXT | Use our proven C-COM software to tune your muscle car, late model, boosted, drag racing, road racing or street car. |
| Description_INV | XFI Sportsman w/ Tbody |
| Description_MKT | Designed for muscle car, late model street and sportsman drag racing engines, along with boosted and individual runner throttle bodyapplications, the FAST XFI Sportsman Engine Control System is a bank-to-bank, fully software-tunable EFI setup. It requires a laptop for tuning and uses FAST C-COM software, which comes packaged along with the necessary USB connectivity cable. A version of the system is now available that includes a 4150-style, eight-injector, 1200-horsepower-capable throttle body to provide easy installation when upgrading a previously carbureted setup. A user-configurable auxiliary input channel is included as well. The system offers both load-indexed Speed Density or Alpha-N fuel strategies |
| Description_MKT | most users will use Speed Density but the Alpha-N option is specifically added to serve sportsman drag racers looking for absolute consistency. The FAST XFI Sportsman System features full tables to monitor fueling, acceleration fuel, timing and air/fuel targets, while full function data logging is also included. It supports both naturally aspirated and boosted applications up to 5 BAR, is compatible with wet nitrous and has nitrous timing retard control. Built-in CAN network support for the EZ-TCU, EZ-LS and XIM means users can easily plug-and-play those components with the included CAN wire. The FAST XFI Sportsman Engine Management System also features a Bosch wide-band 02 sensor, utilizes built-in diagnostic LEDs, a waterproof ECU enclosure and includes a premium, mesh-type, wire loom multi-port harness. Compatible with return-style and returnless fuel systems, XFI Sportsman is designed for use with high-impedance injectors and works with a variety of multi-port systems or either generation of the FAST EZ-EFI throttle body. XFI Sportsman is conveniently configurable to work with FAST distributors, FAST crank triggers, EZ-LS, XIM or the RPM/tach signal from an aftermarket CD ignition box, HEI big cap distributor or included tach adapter. |
| Description_SHO | XFI Sportsman |
| Description_SHP | No |
| Fuel Injection Series | XFI Sportsman |
| height | 14.3 |
| Individual Cylinder Corrections? | No |
| Injection Type | Throttle Body Injection |
| Knock Retard Compatibility? | No |
| Laptop Datalogging Support | Yes |
| length | 20.7 |
| Nitrous Compatible? | Yes |
| Requires Separate Personal Computer? | Yes |
| Title | XFI Sportsman EFI Kit with 4150 Tbody |
| Uses Fuel Pressure Sensor? | Yes |
| weight | 17.24 |
| width | 12.0 |
