Edelbrock 7142 Edelbrock Black Pro Flo LS3 Intake Manifold GM LS Engines
by Edelbrock
SKU ds_BDVJ_7142
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Original price
$1,262.01
-
Original price
$1,262.01
Original price
$1,262.01
$1,262.01
$1,262.01
-
$1,262.01
Current price
$1,262.01
Availability:
Only 1 left!
Description
Edelbrock part #7142 Pro Flo XT LS3 intake manifold is designed for use on GM LS3 engines. This manifold will accept late model LS Drive-By-Wire throttle bodies or Edelbrock 90mm mechanical throttle body and is offered in a black powder coat finish. This manifold is not intended to be a direct replacement for late model vehicle applications due to hood/cowl clearance and emissions incompatibility.
Specifications
| Description_ABR | Intake Mnfld |
| Description_ASM | Chevrolet:Small-Block Gen IV L76:364 (6.0L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L76:364 (6.0L);Chevrolet:Small-Block Gen IV L77:364 (6.0L);Chevrolet:Small-Block Gen IV L92:376 (6.2L);Chevrolet:Small-Block Gen IV L94:376 (6.2L);Chevrolet:Small-Block Gen IV L99:376 (6.2L);Chevrolet:Small-Block Gen IV L9H:37 |
| Description_ASM | Chevrolet:Small-Block Gen IV L77:364 (6.0L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L92:376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L94:376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L99:376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L9H:376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV LS3:376 (6.2L) |
| Description_DEF | Engine Intake Manifold |
| Description_DES | MANIFOLD |
| Description_EXT | Edelbrock Black Pro Flo LS3 Intake Manifold GM LS Engines |
| Description_FAB | 1500-7000+ RPM |
| Description_FAB | 90mm Throttle Bore Opening |
| Description_FAB | Large Plenum And 6.25 in. Tapered Runners |
| Description_FAB | Maximum Horsepower And Broad Torque Band |
| Description_INV | Black Pro Flo XT LS3 Intake Manifold |
| Description_KEY | 7142; Chevy; Chevrolet; Edelbrock; Intake Manifold; Intake; Manifold; EFI; Pro-Flo XT; Black |
| Description_LAB | Black Pro Flo Small Block Chevy LS3 Intake Manifold |
| Description_MKT | Edelbrock part #7142 Pro Flo XT LS3 intake manifold is designed for use on GM LS3 engines. This manifold will accept late model LS Drive-By-Wire throttle bodies or Edelbrock 90mm mechanical throttle body and is offered in a black powder coat finish. This manifold is not intended to be a direct replacement for late model vehicle applications due to hood/cowl clearance and emissions incompatibility. |
| Description_SHO | { Sellable : Yes } |
| Description_SHP | { eo : 2in.} |
| Description_TRA | Manifold Dimensions: A-9.28", B-9.68", C-17.40", D-3.02", E-15 Deg . |
| Description_TRA | Port exit dimensions: 1.23" x 2.52". |
| Description_TRA | Recommended Fuel Rail Kit Edelbrock #3648 Designed for use with standard injectors measure 2.50" from the o-ring center to o-ring enter. Compact injectors measure 1.50" from the o-ring center to o-ring enter. Ends are tapped for use with -8 AN fittings. |
| Description_TRA | Throttle body recommendations: Edelbrock #3869, #38693 or OEM drive-by-wire style. |
| Description_TRA | Uses LS3/ L92/L76 style individual port o-ring seals GM #19256623 or Edelbrock #7395. |
| Description_TRA | • Uses LS3/L92/L76 style individual port o-ring seals GM # 19256623 or Edelbrock # 7395. • Throttle body recommendations: Edelbrock # 3869; # 38693 or OEM drive-by-wire style. • Manifold Dimensions: A-9.28in.; B-9.68in.; C-17.40in.; D-3.02in.; E-15deg. • Port exit dimensions: 1.23in. x 2.52in. • Recommended Fuel Rail Kit Edelbrock # 3648 Designed for use with standard injectors measure 2.50in. from the o-ring center to o-ring enter. Compact injectors measure 1.50in. from the o-ring center to o-ring enter. Ends are tapped for use with-8 AN fittings. |
| height | 13.0 |
| length | 24.0 |
| LTL | N |
| weight | 42.0 |
| width | 15.0 |
