Edelbrock 7032 Edelbrock Tunnel RamTR1-Y Top Only Intake Manifold
by Edelbrock
SKU ds_BDVJ_7032
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$141.95
-
Original price
$141.95
Original price
$141.95
$141.95
-
$141.95
Current price
$141.95
Availability:
Out of stock
Description
Edelbrock part #7032 Street Tunnel Ram Top is designed for 302-327-350-400 c.i.d. small-block Chevy V8's with the Edelbrock Street Tunnel Ram Base #7067 or as a replacement top for the Edelbrock #7110 manifold kit. Great for engines with slightly modified heads. Will not fit 1987 and later cast iron heads. Use with cam kit #5002 for low-end torque or cam kit #7102 for top-end power.
Specifications
| Center Maximum Height | 0.010 |
| CNC Ported | No |
| Color | Satin |
| Description_ABR | Intake Mnfld |
| Description_ASM | Chevrolet:Small-Block Gen I:302 (4.9L)/327 (5.4L)/350 (5.7L)/400 (6.6L) |
| Description_DEF | Engine Intake Manifold |
| Description_EXT | Edelbrock Tunnel RamTR1-Y Top Only Intake Manifold |
| Description_INV | TR1-Y SBC Tunnel Ram Top |
| Description_LAB | TR1-Y Small Block Chevy Top Only Intake Manifold |
| Description_MKT | Edelbrock part #7032 Street Tunnel Ram Top is designed for 302-327-350-400 c.i.d. small-block Chevy V8's with the Edelbrock Street Tunnel Ram Base #7067 or as a replacement top for the Edelbrock #7110 manifold kit. Great for engines with slightly modified heads. Will not fit 1987 and later cast iron heads. Use with cam kit #5002 for low-end torque or cam kit #7102 for top-end power. |
| Description_TRA | Blue loctite recommended for top mounting bolts |
| Description_TRA | Distance from carburetor center to center is 8.875" |
| Description_TRA | Edelbrock #7071 Throttle Linkage (Sideways Mount) |
| Description_TRA | Edelbrock #7097 Throttle Linkage (Forward Mount) |
| Description_TRA | For sideways mounted carburetors, remove the lower linkage on carburetors to clear intake manifold. |
| Description_TRA | For use with Edelbrock Street Tunnel Ram Base #7067 |
| Description_TRA | Manifold will accept forward or sideways mounted 4150-style carburetors. |
| Description_TRA | Top gasket and mounting bolts included |
| Description_TRA | Top has vacuum outlet for power brakes |
| Description_TRA | Top Only |
| Description_TRA | Will accept sideways mounted 4150-style carburetors. |
| Front Maximum Height | 0.010 |
| Gasket Or Seal Included | No |
| Grade Type | Performance |
| height | 7.0 |
| length | 26.75 |
| Material | Aluminum |
| Rear Maximum Height | 0.010 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Single Or Dual Plane Type | Single Plane |
| weight | 8.75 |
| width | 15.5 |
