Edelbrock 61917 Engine Cylinder Head
by Edelbrock
SKU ds_BDVJ_61917
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$709.95
-
Original price
$709.95
Original price
$709.95
$709.95
-
$709.95
Current price
$709.95
Availability:
Out of stock
Description
The Edelbrock part #61917 small-block Chevy LT1 (1992-97) Performer NHRA cylinder heads deliver 24 horsepower over stock and raise the peak power level by 500 rpm. These heads are designed to accept factory style self-aligning rockers. Performer LT1 cylinder heads are 50-state street legal and accept factory center bolt valve covers. They feature exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo. - 61917 Cylinder Heads are allowed for use in the NHRA Super Stock class - Combustion chamber volume: 54cc - Intake runner volume: 170cc - Exhaust runner volume: 60cc - Intake valve diameter: 1.94" - Exhaust valve diameter: 1.55"
Specifications
| Description_ABR | Cyl. Head |
| Description_ASM | Chevrolet:Small-Block Gen II LT1:350 (5.7L) |
| Description_DEF | Engine Cylinder Head |
| Description_EXT | Edelbrock part #61917 Performer small-block Chevy LT1 (1992-97) Performer NHRA cylinder heads deliver 24 horsepower over stock and raise the peak power level by 500 rpm. |
| Description_INV | Edelbrock SBC LT1 Cylinder Head |
| Description_LAB | NHRA LT1 Gen II Small-Block Chevy Super Stock Cylinder Heads |
| Description_MKT | The Edelbrock part #61917 small-block Chevy LT1 (1992-97) Performer NHRA cylinder heads deliver 24 horsepower over stock and raise the peak power level by 500 rpm. These heads are designed to accept factory style self-aligning rockers. Performer LT1 cylinder heads are 50-state street legal and accept factory center bolt valve covers. They feature exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo. - 61917 Cylinder Heads are allowed for use in the NHRA Super Stock class - Combustion chamber volume: 54cc - Intake runner volume: 170cc - Exhaust runner volume: 60cc - Intake valve diameter: 1.94" - Exhaust valve diameter: 1.55" |
| Description_TRA | Bare heads will have valve guides and seats installed, but will require final sizing and a valve job to match the valves you will be using. Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. Match with Edelbrock head gasket sets. |
| height | 7.38 |
| length | 22.75 |
| weight | 24.85 |
| width | 10.44 |
