Edelbrock 618368 Engine Cylinder Head
by Edelbrock
SKU ds_BDVJ_618368
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$2,000.95
-
Original price
$2,000.95
Original price
$2,000.95
$2,000.95
-
$2,000.95
Current price
$2,000.95
Availability:
Out of stock
Description
Edelbrock #618368 is a Fully CNC Ported Version of Pro Port #618369 Head. Features a 14 Deg intake valve, 4.84" bore spacing, & Spread-Port Architecture. HIP treated. Requires Special Valve Train and Sheet Metal Valve Covers.
Specifications
| Description_ABR | Cyl. Head |
| Description_ASM | Chevrolet:Big-Block Race |
| Description_DEF | Engine Cylinder Head |
| Description_EXT | Edelbrock #618368 is a Fully CNC Ported Version of Pro Port #618369 Head. Features a 14 Deg intake valve, 4.84" bore spacing, & Spread-Port Architecture. HIP treated. Requires Special Valve Train and Sheet Metal Valve Covers. |
| Description_INV | Edelbrock BBC Cylinder Head |
| Description_LAB | Pro Port Big Victor Big-Block Chevy 14 Degree Cylinder Head CNC Ported |
| Description_MKT | The Edelbrock 618368 Big Block Chevy 14deg Big Victor cylinder head is intended for high output, large cubic inch racing engines with 4.84" bore spacing. This head is an improvement over existing 18deg designs, such as the Big Chief & Big Duke. The casting is made from A-356 aluminum and is Hot Isostatic Pressing processed (HIP) for superior strength, durability, dimensional stability and exceptional finish quality. These cylinder head features CNC ported intake ports and a raised exhaust runner design for improved flow efficiency. Chambers are fully CNC ported and extra material is included in the deck to allow fine tuning of the combustion chamber design, if desired. Edelbrock and Pat Musi worked with Jesel to improve the valvetrain geometry, delivering Pro-Stock level technology on engines up to 10,000 rpm. Jesel's shaft-mounted system, #KPS-387154, is made from lightweight 7000 series aluminum and features a one-piece stand design that pairs the intake and exhaust stands for improved valvetrain stability. The intake features a 1.820" long fulcrum and is available in 1.60:1 - 1.95:1 rocker ratios |
| Description_MKT | the exhaust features a 2.000" long fulcrum and available in 1.60:1 - 2.00:1 rocker ratios. Requires Edelbrock valve covers #4259. |
| Description_TRA | Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat |
| height | 9.5 |
| length | 26.0 |
| weight | 43.4 |
| width | 11.0 |
