Edelbrock 605515 Engine Cylinder Head
by Edelbrock
SKU ds_BDVJ_605515
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$2,027.47
-
Original price
$2,027.47
Original price
$2,027.47
$2,027.47
$2,027.47
-
$2,027.47
Current price
$2,027.47
Availability:
Out of stock
Description
The Edelbrock #605515 Performer RPM Rectangle Port cylinder heads are designed for Big-Block Chevy applications. The Edelbrock #605515 Performer RPM heads are perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. These cylinder heads deliver great throttle response and power from 2500 to 7000 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Resources
Installation InstructionsSpecifications
| CNC Ported | No |
| Combustion Chamber Volume | 118.0 |
| Deck Thickness | 0.562 |
| Description_ABR | Cyl. Head |
| Description_ASM | Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Description_DEF | Engine Cylinder Head |
| Description_EXT | Edelbrock part #605515 Performer RPM Rectangle Port cylinder heads are designed for Big-Block Chevy applications. |
| Description_INV | Edelbrock BBC Cylinder Head |
| Description_LAB | RPM Big-Block Chevy Rectangular Port Cylinder Head Roller Polished |
| Description_MKT | The Edelbrock #605515 Performer RPM Rectangle Port cylinder heads are designed for Big-Block Chevy applications. The Edelbrock #605515 Performer RPM heads are perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. These cylinder heads deliver great throttle response and power from 2500 to 7000 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only. |
| Description_TRA | All Performer and Performer RPM Big-Block Chevy heads: Spark plug is closer to center of bore, will interfere with high-dome pistons for open chamber heads. |
| Description_TRA | Designed for street/high-performance big-blocks operating from 2500-7000 rpm |
| Description_TRA | EQUIPPED WITH SPRINGS FOR USE IN HYDRAULIC ROLLER CAMSHAFT APPLICATIONS |
| Description_TRA | High-velocity 315cc long/300cc short intake ports |
| Description_TRA | Highly-efficient 118cc open-style combustion chamber |
| Description_TRA | Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. |
| Description_TRA | Smaller-than-stock 11/32" valve stems promote excellent flow and lighter valve weight |
| Description_TRA | Specially designed ports for increased flow and velocity over standard big-block cylinder heads |
| Description_TRA | Use pistons designed for our heads. Match with Edelbrock head gasket sets. |
| Exhaust Valve Diameter | 1.880 |
| Grade Type | Performance |
| Guide Plate Material | Hardened Steel |
| Guide Plates Included | Yes |
| Head Casting Number | 31-6055 |
| height | 8.25 |
| Intake Runner Volume | 315.0 |
| Intake Valve Diameter | 2.190 |
| length | 24.75 |
| Material | Aluminum |
| Push Rod Diameter | 0.375 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Valve Angle | 26 |
| Valve Spring Diameter | 1.550 |
| Valve Spring Maximum Lift | 0.700 |
| Valve Stem Diameter | 0.341 |
| weight | 43.4 |
| width | 10.5 |
