Edelbrock 5822 Engine Valve Spring
by Edelbrock
SKU ds_BDVJ_5822
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$61.06
-
Original price
$61.06
Original price
$61.06
$61.06
-
$61.06
Current price
$61.06
Availability:
Out of stock
Description
The Edelbrock #5822 Sure Seat Valve Spring for Ford 289-302 V8 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application.
Specifications
| Camshaft Type | Hydraulic Flat Tappet |
| Coil Bind Height | 1.200 |
| Description_ABR | Valve Sprng |
| Description_ASM | Ford:Small-Block Windsor:289 (4.7L)/302 (5.0L) |
| Description_DEF | Engine Valve Spring |
| Description_EXT | The Edelbrock #5822 Sure Seat Valve Spring for Ford 289-302 V8 O.E Cast iron cylinder heads are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. |
| Description_INV | Edelbrock Sure Seat Valve Springs |
| Description_LAB | Sure Seat Valve Springs for Ford 289-302 |
| Description_MKT | The Edelbrock #5822 Sure Seat Valve Spring for Ford 289-302 V8 O.E Cast iron cylinder heads are made of highest quality spring wire and precision wound to close tolerances, our Sure Seat Valve Spring sets are for use on original equipment heads when installing Edelbrock Performer-Plus, Performer RPM and Torker-Plus camshafts. These are the same high-performance springs used on Edelbrock Performer and RPM cylinder heads. For camshaft warranty compliance, use only the springs recommended by Edelbrock for each camshaft application. |
| Description_TRA | Non-Rotator springs |
| Description_TRA | Recommended Edelbrock Cams: All Performer Camshafts |
| Grade Type | Performance |
| height | 2.25 |
| Inside Diameter | 1.010 |
| Installed Height | 1.700 |
| Installed Pressure | 90 |
| length | 12.25 |
| Material | Steel |
| Open Pressure | 210 |
| Outside Diameter | 1.354 |
| RGL | WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Spring Type | Single Coil |
| weight | 3.0 |
| width | 3.38 |
