Edelbrock 45274 Engine Complete Assembly
by Edelbrock
SKU ds_BDVJ_45274
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$20,594.00
-
Original price
$20,594.00
Original price
$20,594.00
$20,594.00
$20,594.00
-
$20,594.00
Current price
$20,594.00
Availability:
Out of stock
Description
Edelbrock part #45274 Performer RPM small-block Ford 347 crate engine offers the best of quality and performance with 438 HP & 413 ft/lbs. of torque. This engine combines a Dart cast iron 4 bolt main block and a forged Scat rotating assembly with the Edelbrock Power Package parts. This Performer RPM 347 engine includes a Milodon oil pan and pickup designed for use with 1974 and later applications as well as street rods that require a rear sump to clear the crossmember and/or suspension Engine Specifications: - Finish: EnduraShine - Displacement: 347 c.i.d. - Horsepower: 438 hp - Torque: 413 ft-lbs. - Compression: 9.5:1 - Block: Dart Small-block (8.2" deck height) - Crankshaft: Scat Forged Steel - Pistons: Scat Forged - Camshaft: Rollin' Thunder Hydraulic Roller #2281 - Rocker Arms: 1.6:1 Roller #77780 - Manifold: RPM Air-Gap #75214 - Cylinder Heads: Performer RPM #602515 - Carburetor: Thunder Series AVS 800 cfm - Water Pump: Victor series aluminum #88414 - Distributor: Included - Valve Covers: Elite II - Warranty: 2-year / Unlimited mileage
Resources
Installation InstructionsSpecifications
| Camshaft Type | Rollin' Thunder, Hydraulic Roller |
| Carburetor Type | Thunder AVS 800 CFM, Satin |
| Compression Ratio | 9.5:1 |
| Construction Type | Assembled |
| Cylinder Head Type | Performer RPM |
| Description_ABR | CRATE ENGINE |
| Description_ASM | Ford:Small-Block Windsor:260 (4.3L)/289 (4.7L)/302 (5.0L) |
| Description_DEF | Engine Complete Assembly |
| Description_EXT | Edelbrock part #45274 Performer RPM 347 small-block Ford crate engine (rear sump oil pan) offers the best of quality and performance with 438 HP & 413 ft/lbs of torque right out of the crate |
| Description_INV | Performer RPM 347 Ford crate engine |
| Description_LAB | Performer RPM 347 Ford Crate Engine |
| Description_MKT | Edelbrock part #45274 Performer RPM small-block Ford 347 crate engine offers the best of quality and performance with 438 HP & 413 ft/lbs. of torque. This engine combines a Dart cast iron 4 bolt main block and a forged Scat rotating assembly with the Edelbrock Power Package parts. This Performer RPM 347 engine includes a Milodon oil pan and pickup designed for use with 1974 and later applications as well as street rods that require a rear sump to clear the crossmember and/or suspension Engine Specifications: - Finish: EnduraShine - Displacement: 347 c.i.d. - Horsepower: 438 hp - Torque: 413 ft-lbs. - Compression: 9.5:1 - Block: Dart Small-block (8.2" deck height) - Crankshaft: Scat Forged Steel - Pistons: Scat Forged - Camshaft: Rollin' Thunder Hydraulic Roller #2281 - Rocker Arms: 1.6:1 Roller #77780 - Manifold: RPM Air-Gap #75214 - Cylinder Heads: Performer RPM #602515 - Carburetor: Thunder Series AVS 800 cfm - Water Pump: Victor series aluminum #88414 - Distributor: Included - Valve Covers: Elite II - Warranty: 2-year / Unlimited mileage |
| Description_TRA | Any dipstick holes that are not used must be plugged. The threaded provision on the Milodon oil pan will require a 5/8"-18 plug. Remove any paint from the engine mount bosses, cylinder block to clutch housing or transmission mounting surface, and the crankshaft flange before installing engine. |
| Description_TRA | Equipped with 3-bolt pulley damper, right-hand inlet water pump and left-hand timing pointer. Optional 4-bolt pulley damper, left-hand inlet water pump and right-hand timing pointer available by request. |
| Description_TRA | Rear sump engines can install a Milodon dipstick (Milodon #22040) into the threaded hole on the oil pan or an OEM dipstick (Ford #M-6750-C303) into the block directly above the oil pan bung. |
| Description_TRA | There is no oil in your engine. |
| Description_TRA | Your engine is supplied with 6 Qtrs. of Edelbrock Break-In Oil in the crate. Before starting engine, you will need to prime the oil system. |
| Flywheel Included | No |
| Grade Type | Performance |
| Hardware Included | Yes |
| height | 31.0 |
| Horsepower | 438 |
| Intake Manifold Type | Performer RPM Air-Gap, Dual 4150, EnduraShine |
| length | 40.0 |
| Manifold Material | Aluminum |
| Quantity | Sold Individually |
| RGL | WARNING: This product can expose you to Chromium, Lead, and Zinc which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Rocker Arm Ratio | 1.6:1 |
| Rocker Arm Type | Roller |
| Spark Plugs Included | No |
| Torque | 413 |
| Type | Small-Block Ford |
| Universal Or Specific Fit | Specific Fit |
| Valve Cover Type | Elite II, Tall Profile, Polished |
| weight | 460.0 |
| width | 27.0 |
| Wire Harness Included | No |
