Description
3697 is a set of 8, short body Siemens high impedance (12.5 Ohms) fuel injectors with a flow rate of 60 lb/hr (630cc/min) @ 43.5psi. These injectors measure 37.25mm o-ring to o-ring centerline, feature EV1 style connector with a blue band around them for identification and are capable of supporting up to 825HP @ 43 psi with the Pro-Flo 4 EFI system. These injectors are offered as a replacement or upgrade for Pro-Flo EFI systems and are compatible with many OEM and aftermarket EFI systems.
Specifications
| Body Type | Short |
| Description_ABR | Fuel Injectr |
| Description_ASM | Universal |
| Description_DEF | Fuel Injector |
| Description_EXT | Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc/min) @43.5psi. EV1 style connectors with a Blue Band around them for identification. |
| Description_INV | Fuel Injector 60 Lb/Hr Short (Set of 8) |
| Description_LAB | Fuel Injector #3697 Siemens 60 lb/hr (630cc/min) @ 43.5psi, Set of 8 |
| Description_MKT | 3697 is a set of 8, short body Siemens high impedance (12.5 Ohms) fuel injectors with a flow rate of 60 lb/hr (630cc/min) @ 43.5psi. These injectors measure 37.25mm o-ring to o-ring centerline, feature EV1 style connector with a blue band around them for identification and are capable of supporting up to 825HP @ 43 psi with the Pro-Flo 4 EFI system. These injectors are offered as a replacement or upgrade for Pro-Flo EFI systems and are compatible with many OEM and aftermarket EFI systems. |
| Description_SLA | Short Body Siemens High Impedance (12.5 ohms) Fuel Injector with a flow rate of 60 lb/hr (630cc/min) @43.5psi. These injectors measure 37.25mm O-ring to O-ring centerline, feature EV1 style connectors with a Blue Band around them for identification and are capable of up to 825HP @ 43psi when run as a set of 8 with ProFlo EFI. These injectors are offered as a replacement or upgrade for the ProFlo EFI Systems and are compatible with many OEM and aftermarket EFI systems. |
| Flow Rate | 60 |
| height | 5.812 |
| Impedance | 12.5 |
| Injection Type | EFI - Port Injection |
| length | 11.625 |
| Pressure Rating | 43.5 |
| Quantity | Set of 8 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Type | Siemens |
| weight | 1.0 |
| width | 7.125 |
| Wiring Harness Included | No |
