Edelbrock 35990 Fuel Injection System
by Edelbrock
SKU ds_BDVJ_35990
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$2,978.85
-
Original price
$2,978.85
Original price
$2,978.85
$2,978.85
$2,978.85
-
$2,978.85
Current price
$2,978.85
Description
The Edelbrock Pro-Flo 4 XT EFI Kit #35990 for Chevrolet LS GEN III/IV engines is equipped with the latest technology and features. The EFI system comes complete with a Pro-Flo XT cathedral port black finish intake manifold and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure. The new Pro-Flo 4 EFI systems feature an all-new ECU with a faster processor, a water proof design and measures half the depth of the previous ECU. It also has an upgraded Bluetooth chip that is faster, more reliable and will not drop connection. We've added more features for the advanced tuner giving you control over air-fuel ratios, ignition curve, idle speed, acceleration fuel, coolant fans, Rev limiter while retaining the simplicity Pro-Flo is known for. The key to the system is our exclusive E-Tuner 4 app with dyno developed base calibrations. The E-Tuner 4 app uses a Bluetooth wireless connection to communicate with the ECU's self-learning capability to continually adjust the calibration to get the maximize performance of your engine. E-Tuner 4 features a simple and easy to use setup wizard to help you get started as well as multiple dash displays so you can monitor your engines vitals and performance. The exclusive Edelbrock E-Tuner 4 app is Free and Available for Android and IOS based smart phone or tablet.
Specifications
| Bore Diameter | 90 |
| Description_ABR | EFI System |
| Description_ASM | Chevrolet:Small-Block Gen IV L76:364 (6.0L)/376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L92:364 (6.0L)/376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV L99:364 (6.0L)/376 (6.2L) |
| Description_ASM | Chevrolet:Small-Block Gen IV LS3:364 (6.0L)/376 (6.2L) |
| Description_DEF | Fuel Injection System |
| Description_EXT | Edelbrock Pro-Flo 4 XT EFI System for Chevrolet LS GEN III/IV engines. The EFI system comes with a Pro-Flo XT rectangle port intake manifold and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure. |
| Description_INV | Edel Pro-Flo 4 XT EFI Sys LS Gen III/IV |
| Description_LAB | Pro-Flo 4 EFI XT-Style Kit #35990 For Chevy LS Gen III/IV Small-Block |
| Description_MKT | The Edelbrock Pro-Flo 4 XT EFI Kit #35990 for Chevrolet LS GEN III/IV engines is equipped with the latest technology and features. The EFI system comes complete with a Pro-Flo XT cathedral port black finish intake manifold and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure. The new Pro-Flo 4 EFI systems feature an all-new ECU with a faster processor, a water proof design and measures half the depth of the previous ECU. It also has an upgraded Bluetooth chip that is faster, more reliable and will not drop connection. We've added more features for the advanced tuner giving you control over air-fuel ratios, ignition curve, idle speed, acceleration fuel, coolant fans, Rev limiter while retaining the simplicity Pro-Flo is known for. The key to the system is our exclusive E-Tuner 4 app with dyno developed base calibrations. The E-Tuner 4 app uses a Bluetooth wireless connection to communicate with the ECU's self-learning capability to continually adjust the calibration to get the maximize performance of your engine. E-Tuner 4 features a simple and easy to use setup wizard to help you get started as well as multiple dash displays so you can monitor your engines vitals and performance. The exclusive Edelbrock E-Tuner 4 app is Free and Available for Android and IOS based smart phone or tablet. |
| Description_TRA | This kit will require a high pressure EFI fuel delivery system. Fuel delivery systems are available and sold separately. LS kits will require a coil harness which is sold separately. 24(x) reluctor applications will require #37-1633 and 58(x) reluctor applications will require #37-1632. For the heights of all Edelbrock manifolds please visit the Manifold Reference Dimensions page. |
| Distributor Cap Included | Yes |
| finish | Satin |
| Flange Type | XT-Style |
| Fuel Injector Type | 35 lb/hr |
| Fuel Pressure Port | 1/8-27 NPT |
| Gasket Or Seal Included | Yes |
| height | 10.312 |
| length | 30.188 |
| Manifold Height | A-10.2 in, B-10.0 in, C-16.9 in, D-3.2 in, E-15 Degrees |
| Maximum Horsepower | 550 |
| Quantity | Kit |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| System Type | XT-Style Kit |
| Throttle Body Type | Single Blade |
| weight | 52.0 |
| width | 25.25 |
| Wire Harness Included | Yes |
| Wiring Harness Included | Yes |
