Edelbrock 290251 Engine Intake Manifold
by Edelbrock
SKU ds_BDVJ_290251
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$685.95
-
Original price
$685.95
Original price
$685.95
$685.95
-
$685.95
Current price
$685.95
Availability:
Out of stock
Description
Edelbrock part #290251 Victor Jr. 454-R EFI intake manifold is designed for competition rectangular port 396-502 big-block Chevy applications. This Edelbrock Single-plane, high-rise EFI intake is designed for maximum race-winning power at higher engine speeds. Edelbrock engineers work in conjunction with leading engine builders from all forms of competition to design manifolds compatible with the latest technology. Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. This manifold offers a polished finish for a brilliant shine and classic look.
Specifications
| Center Maximum Height | 5.960 |
| CNC Ported | No |
| Description_ABR | Intake Mnfld |
| Description_ASM | Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Description_DEF | Engine Intake Manifold |
| Description_EXT | Edelbrock Victor Jr. 454-R EFI Intake Manifold For Chevrolet 396-502 Big-Block V8 |
| Description_INV | Polished Vic Jr BBC Rectangular Port EFI |
| Description_LAB | Victor Jr. Big Block Chevy 454-R EFI Intake Manifold |
| Description_MKT | Edelbrock part #290251 Victor Jr. 454-R EFI intake manifold is designed for competition rectangular port 396-502 big-block Chevy applications. This Edelbrock Single-plane, high-rise EFI intake is designed for maximum race-winning power at higher engine speeds. Edelbrock engineers work in conjunction with leading engine builders from all forms of competition to design manifolds compatible with the latest technology. Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. This manifold offers a polished finish for a brilliant shine and classic look. |
| Description_TRA | Manifold height: A-5.90" & B-5.90" |
| Description_TRA | Recommended intake gasket: Edelbrock #7208 |
| Description_TRA | Throttle Body Recommendations: Use #3878 4V series or #3849 EFI elbow and #3869 90mm throttle body. |
| finish | Polished |
| Front Maximum Height | 5.960 |
| Gasket Or Seal Included | No |
| Grade Type | Performance |
| height | 7.5 |
| length | 23.625 |
| Material | Aluminum |
| Rear Maximum Height | 5.960 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Single Or Dual Plane Type | Single Plane |
| weight | 21.3 |
| width | 14.75 |
