Edelbrock 2848 XX 2 PIECE MANIFOLD ROX SBC 4.5 BORE CENTER DIRT LATE MODEL STD FLANGE VERSION
by Edelbrock
SKU ds_BDVJ_2848
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$837.30
Original price
$837.30
-
Original price
$837.30
Original price
$837.30
Current price
$721.81
$721.81
-
$721.81
Current price
$721.81
Availability:
Out of stock
Description
The Victor Two-Piece manifolds were developed to simplify CNC manifold porting. They are supplied in right and left halves that can be machined and then assembled with the supplied bolts and o-ring. Victor Two-Piece manifolds are available for various applications from standard 9" deck 18° cylinder heads to 9.3" deck Clements/Dart 13° cylinder heads as well as SB2 and ROX engines. They are also offered in varying flange thicknesses to accommodate multiple applications. INSTALLATION NOTE: Conventional 18° applications will require additional machining of manifold and valley plate for desired clearance when using valley plate #2855. Valley plate #2992 can also be used when less machining is desired. When using thick flange manifolds, machining of backside of flange is recommended for weight reduction.
Specifications
| Basic Operating RPM Range | 5000-8500 |
| Cylinder Head Type | Standard |
| Description_ASM | Chevrolet:Small-Block Gen I Race |
| Description_DEF | Engine Intake Manifold |
| Description_DES | INTAKE MANIFOLD |
| Description_EXT | 4.5 Bore Center Dirt Late Model |
| Description_EXT | Edelbrock 2-Piece Intake Manifold |
| Description_EXT | R0X SBC |
| Description_EXT | Standard and +.500? Flange |
| Description_EXT | XX 2 PIECE MANIFOLD ROX SBC 4.5 BORE CENTER DIRT LATE MODEL STD FLANGE VERSION |
| Description_FAB | Assembled w/Shoulder Bolts And 3/32 in. O-Ring |
| Description_FAB | For 5000 to 8500 RPM High-Performance Engines |
| Description_FAB | NASCAR Approved for 2006 Season |
| Description_FAB | Right And Left Halves Machined Separately |
| Description_FAB | Standard Internal Casting |
| Description_INV | INTAKE MANIFOLD |
| Description_LAB | Two-Piece Manifold SB Chevy ROX 4.5 Bore Center Dirt Late-Model Std Flange |
| Description_MKT | Small Block Chevrolet intake for Dirt Late model. This is a 2-piece Spider-type manifold. The 2 halves will be assembled using o-rings and shoulder bolt hardware supplied. Machined for standard 9” deck configuration. |
| Description_MKT | The Victor Two-Piece manifolds were developed to simplify CNC manifold porting. They are supplied in right and left halves that can be machined and then assembled with the supplied bolts and o-ring. Victor Two-Piece manifolds are available for various applications from standard 9" deck 18° cylinder heads to 9.3" deck Clements/Dart 13° cylinder heads as well as SB2 and ROX engines. They are also offered in varying flange thicknesses to accommodate multiple applications. INSTALLATION NOTE: Conventional 18° applications will require additional machining of manifold and valley plate for desired clearance when using valley plate #2855. Valley plate #2992 can also be used when less machining is desired. When using thick flange manifolds, machining of backside of flange is recommended for weight reduction. |
| Description_SHO | { Sellable : Yes } |
| Description_TRA | Bore Center 4.4" |
| Description_TRA | Conventional 18 Deg applications will require additional machining of manifold and valley plate for desired clearance when using valley plate #2855. |
| Description_TRA | Edelbrock Valley plate #2992 can also be used when less machining is desired. When using thick flange manifolds, machining of backside of flange is recommended for weight reduction. |
| Description_TRA | Flange Thickness Standard |
| Description_TRA | Maximum Deck Height 9.080" |
| Description_TRA | • Bore Center 4.4in. • Flange Thickness Standard • Maximum Deck Height 9.080in. • Conventional 18deg. applications will require additional machining of manifold and valley plate for desired clearance when using valley plate #2855. • Edelbrock Valley plate #2992 can also be used when less machining is desired. When using thick flange manifolds; machining of backside of flange is recommended for weight reduction. |
| EGR Port | No |
| Emission | N/A |
| Engine Make/Size | Chevy Small Block (262-400) |
| Flange Type | 4150 |
| Grade Type | Performance |
| height | 9.5 |
| length | 24.25 |
| Number of Carbs | One |
| Position | N/A |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range | 5000-8500 |
| Series | Victor |
| Single Or Dual Plane Type | Single |
| Usage | Racing |
| Vehicle Model | Chevrolet |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| weight | 23.75 |
| width | 16.5 |
