Eagle Specialty Prod 442636226100 4340 Crank Chevy LS9, 58T LS2 RELUCTOR
SKU ds_CFQW_442636226100
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$1,695.36
-
Original price
$1,695.36
Original price
$1,695.36
$1,695.36
$1,695.36
-
$1,695.36
Current price
$1,695.36
Availability:
Out of stock
Description
Eagle forged 4340 steel Cranks feature a non-twist forging, .125" fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface and micropolished. Intended for the most demanding applications. Includes 58 tooth LS9 reluctor.
Specifications
| Description_ASC | 9 bolt rear flange, 58 tooth LS2 reluctor |
| Description_ASC | Crankshaft must be balanced to match your specific Rods and pistons. |
| Description_DEF | Engine Crankshaft |
| Description_DES | 4340 Crank Chevy LS9, 58T LS2 RELUCTOR |
| Description_EXT | Forged 4340 Steel Crank - Chevrolet LS9 LONG SNOUT, 3.622" Stroke, 58 TOOTH LS2 RELUCTOR REQUIRES LS2 SENSOR. |
| Description_INV | ESP 4340 Crank |
| Description_MKT | Eagle forged 4340 steel Cranks feature a non-twist forging, .125" fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface and micropolished. Intended for the most demanding applications. Includes 58 tooth LS9 reluctor. |
| Description_SHO | 4340 Crank |
| Engine Stroke | 2.559 |
| height | 9.0 |
| Intended Balance | internal |
| length | 32.0 |
| LTL | N |
| Material | Forged 4340 Steel |
| Minimum Rod Length | 6.100" |
| Prop 65 (C, R or CR) | C |
| Prop 65 - Short Label | prop65_warning.jpg |
| Prop 65 Yes/No | Yes |
| Rod Journal Diameter | 2.1 |
| Title | ESP 4340 Crank Chevy LS9, 58T LS2 RELUCTOR |
| weight | 62.0 |
| width | 9.0 |
