Eagle Specialty Prod 428237502000 Forged 4340 Steel Crank - Ford 5.0L COYOTE, 3.750" Stroke, 2.000" Rod JournalS.
SKU ds_CFQW_428237502000
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$1,678.19
-
Original price
$1,678.19
Original price
$1,678.19
$1,678.19
$1,678.19
-
$1,678.19
Current price
$1,678.19
Availability:
Out of stock
Description
Eagle forged 4340 steel center-counterweighted Cranks feature a non-twist forging, center counterweights for added stability at high RPM and high-power applications. 125" fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface and micropolished. Intended for the most demanding applications.
Specifications
| Description_ASC | Crankshaft must be balanced to match your specific Rods and pistons. |
| Description_DEF | Engine Crankshaft |
| Description_DES | 4340 CRANK Ford Coyote 3.750" 2.00 Rod |
| Description_EXT | Forged 4340 Steel Crank - Ford 5.0L COYOTE, 3.750" Stroke, 2.000" Rod JournalS. |
| Description_INV | ESP 4340 Crank |
| Description_MKT | Eagle forged 4340 steel center-counterweighted Cranks feature a non-twist forging, center counterweights for added stability at high RPM and high-power applications. 125" fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface and micropolished. Intended for the most demanding applications. |
| Description_SHO | 4340 Crank |
| height | 9.0 |
| Intended Balance | Internal |
| length | 32.0 |
| LTL | N |
| Material | Forged 4340 Steel |
| Minimum Rod Length | 5.950" |
| Prop 65 (C, R or CR) | C |
| Prop 65 - Short Label | prop65_warning.jpg |
| Prop 65 Yes/No | Yes |
| Title | ESP 4340 CRANK FORD COYOTE 3.750" 2.00 ROD |
| weight | 53.0 |
| width | 9.0 |
