CURT 15511 Class 5 Multi-Fit Trailer Hitch with 2in. Receiver
by CURT
SKU ds_BKDK_15511
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Save $121.24
Original price
$642.70
Original price
$642.70
-
Original price
$642.70
Original price
$642.70
Current price
$521.46
$521.46
-
$521.46
Current price
$521.46
Availability:
Only 4 left!
Description
When a custom hitch is not available for your vehicle, CURT offers the multi-fit hitch. Designed to be the ultimate in versatility, CURT universal trailer hitches fit several different vehicle manufacturers, including Chevy, GMC, Dodge, Ford and more. The multi-fit hitch is a universally designed alternative to our custom hitches. It provides a more affordable option and flexibility in installation. Very simply, a CURT multi-fit trailer hitch uses a sliding or adjustable frame to match the width of your vehicles frame. In general, multi-fit hitches are used on mid-size and full-size pickup trucks and class 5 multi-fit trailer hitch features a gross trailer weight capacity of 15,000 lbs., a tongue weight capacity of 1,500 lbs. and a 2" x 2" receiver tube opening, making it an excellent choice for towing toy haulers, dump trailers, logging trailers, gravity boxes, small yacht trailers, as well as cargo carriers, bike racks and winch mounts. For a little extra towing power and stability, this multi-fit hitch can also be used in combination with a weight distribution system, bringing its gross trailer weight capacity up to 16,000 lbs. and its tongue weight capacity up to 1,600 lbs. (NOTE: Never exceed the lowest weight capacity of any towing component).
Resources
Installation InstructionsSpecifications
| Body Shape | Square |
| Box Height in Inches - XA | 19 |
| Box Length in Inches - XA | 41 |
| Box Width in Inches - XA | 9 |
| Class ID | 0 |
| Description_ABR | CL 5 |
| Description_ASC | Class 5 Multi-Fit Trailer Hitch with 2" Receiver |
| Description_ASC | Equipped with an open-back receiver for easy cleaning |
| Description_ASC | Features multiple mounting holes to fit a variety of vehicles |
| Description_ASC | Limited lifetime warranty (one-year finish, one-year parts) |
| Description_ASC | Precisely welded for superior strength and fit |
| Description_ASC | Protected by a highly durable carbide powder coat finish |
| Description_ASC | Tested for safety in accordance with SAE J684 |
| Description_ASM | CURT 15511 Multi-Fit Class 5 Adjustable Hitch, 7-1/2-Inch Drop, 2-Inch Receiver, 15,000 lbs. Select Chevrolet, Dodge, Ford, GMC Trucks |
| Description_DEF | Trailer Hitch |
| Description_DES | Class 5 Multi-Fit Trailer Hitch with 2" Receiver |
| Description_DES | Class 5 Multi-Fit Trailer Hitch with 2in. Receiver |
| Description_EXT | CURT 15511 Multi-Fit Class 5 Adjustable Hitch, 7-1/2-Inch Drop, 2-Inch Receiver, 15,000 lbs. Select Chevrolet, Dodge, Ford, GMC Trucks |
| Description_EXT | CURT 15511 Multi-Fit Class 5 Adjustable Hitch; 7-1/2-Inch Drop; 2-Inch Receiver; 15;000 lbs. Select Chevrolet; Dodge; Ford; GMC Trucks |
| Description_FAB | Backed By A Limited Lifetime Warranty |
| Description_FAB | Co-Cured In A Rust-Resistant Liquid Bonderite Coating |
| Description_FAB | Equipped w/An Open-Back Receiver For Easy Cleaning |
| Description_FAB | Features Multiple Mounting Holes To Fit A Variety Of Vehicles |
| Description_FAB | Made in USA [may include imported hardware] |
| Description_FAB | Protected By A Highly Durable Carbide Powder Coat Finish |
| Description_FAB | Robotically Welded For Superior Strength And Fit |
| Description_FAB | Strengthened w/A Cast Welded Seamless Collar |
| Description_FAB | Tested For Safety In Accordance w/SAE J684 |
| Description_INV | Class 5 Multi-Fit Trailer Hitch |
| Description_KEY | tow distributing truck 2 inch package parts receivers kit multi pick up under multifit draw accessories square hitchs reciever hitchrs reciver tubes 2in drill hich model v |
| Description_LAB | Made In Logo |
| Description_MKT | When a custom hitch is not available for your vehicle, CURT offers the multi-fit hitch. Designed to be the ultimate in versatility, CURT universal trailer hitches fit several different vehicle manufacturers, including Chevy, GMC, Dodge, Ford and more. The multi-fit hitch is a universally designed alternative to our custom hitches. It provides a more affordable option and flexibility in installation. Very simply, a CURT multi-fit trailer hitch uses a sliding or adjustable frame to match the width of your vehicle's frame. In general, multi-fit hitches are used on mid-size and full-size pickup trucks and class 5 multi-fit trailer hitch features a gross trailer weight capacity of 15,000 lbs., a tongue weight capacity of 1,500 lbs. and a 2" x 2" receiver tube opening, making it an excellent choice for towing toy haulers, dump trailers, logging trailers, gravity boxes, small yacht trailers, as well as cargo carriers, bike racks and winch mounts. For a little extra towing power and stability, this multi-fit hitch can also be used in combination with a weight distribution system, bringing its gross trailer weight capacity up to 16,000 lbs. and its tongue weight capacity up to 1,600 lbs. (NOTE: Never exceed the lowest weight capacity of any towing component). |
| Description_MKT | When a custom hitch is not available for your vehicle, CURT offers the multi-fit hitch. Designed to be the ultimate in versatility, CURT universal trailer hitches fit several different vehicle manufacturers, including Chevy, GMC, Dodge, Ford and more. The multi-fit hitch is a universally designed alternative to our custom hitches. It provides a more affordable option and flexibility in installation. Very simply, a CURT multi-fit trailer hitch uses a sliding or adjustable frame to match the width of your vehicles frame. In general, multi-fit hitches are used on mid-size and full-size pickup trucks and class 5 multi-fit trailer hitch features a gross trailer weight capacity of 15,000 lbs., a tongue weight capacity of 1,500 lbs. and a 2" x 2" receiver tube opening, making it an excellent choice for towing toy haulers, dump trailers, logging trailers, gravity boxes, small yacht trailers, as well as cargo carriers, bike racks and winch mounts. For a little extra towing power and stability, this multi-fit hitch can also be used in combination with a weight distribution system, bringing its gross trailer weight capacity up to 16,000 lbs. and its tongue weight capacity up to 1,600 lbs. (NOTE: Never exceed the lowest weight capacity of any towing component). |
| Description_SHO | Class 5 Multi-Fit Tr |
| Description_SHO | Multi-Fit Hitch |
| Description_SLA | When a custom hitch is not available for your vehicle, CURT offers the multi-fit hitch. Designed to be the ultimate in versatility, CURT universal trailer hitches fit several different vehicle manufacturers, including Chevy, GMC, Dodge, Ford and more. The multi-fit hitch is a universally designed alternative to our custom hitches. It provides a more affordable option and flexibility in installation. Very simply, a CURT multi-fit trailer hitch uses a sliding or adjustable frame to match the width of your vehicle's frame. In general, multi-fit hitches are used on mid-size and full-size pickup trucks and class 5 multi-fit trailer hitch features a gross trailer weight capacity of 15,000 lbs., a tongue weight capacity of 1,500 lbs. and a 2" x 2" receiver tube opening, making it an excellent choice for towing toy haulers, dump trailers, logging trailers, gravity boxes, small yacht trailers, as well as cargo carriers, bike racks and winch mounts. For a little extra towing power and stability, this multi-fit hitch can also be used in combination with a weight distribution system, bringing its gross trailer weight capacity up to 16,000 lbs. and its tongue weight capacity up to 1,600 lbs. (NOTE: Never exceed the lowest weight capacity of any towing component). |
| Drilling Required | Yes |
| Drop | 7 1/2 IN |
| finish | Carbide Black Powder Coat |
| Finish - XA | CARBIDE BLACK POWDER COAT |
| Gross Trailer Weight | 15000 lbs. |
| Gross Trailer Weight (GTW) | 15,000 LB |
| height | 10.0 |
| Item Class - XA | MFH |
| Item Height - XA | 8.750 |
| Item Length - XA | 41.000 |
| Item Width - XA | 18.500 |
| length | 42.0 |
| LTL | N |
| Main Body Shape | Square |
| Parcel Allowed - XA | Yes |
| Position | Rear |
| Product Weight - XA | 62.000 |
| Rate Class - XA | 70.0 |
| Receiver Tube Size | 2 IN |
| Receiver Tube Size | 2.000 in. |
| Retail Height - XA | 10.000 |
| Retail Length - XA | 42.000 |
| Retail Width - XA | 21.000 |
| Shipping Weight - XA | 67.000 |
| Tariff 301 - XA | No |
| Title | Class 5 Multi-Fit Trailer Hitch with 2" Receiver |
| Tongue Weight (TW) | 1,500 LB |
| WARNING CA Proposition 65 | No |
| Warranty | Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| weight | 67.0 |
| Weight Carrying Capacity (WC) | 15,000 LB |
| Weight Distribution (WD) | 16,000 LB |
| Weight Distribution Tongue Weight (WDTW) | 1,600 LB |
| width | 21.0 |
