COMP Cams 7228TSD-KIT Conical .625" Max Lift Valve Spring Kit for GM GEN V LT4 w/ Tool Steel Retainers
by COMP Cams
SKU ds_BDQQ_7228TSD-KIT
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Sold out
Original price
$1,048.22
-
Original price
$1,048.22
Original price
$1,048.22
$1,048.22
$1,048.22
-
$1,048.22
Current price
$1,048.22
Availability:
Out of stock
Description
Conical .625" Max Lift Valve Spring Kit for GM GEN V LT4 w/ Tool Steel Retainers
Resources
Installation InstructionsResources
Installation InstructionsSpecifications
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Cam Type | Hydraulic Roller |
| Coil Bind Height | 1.125 |
| Damper | No |
| Description_ASC | Available in a Beehive Spring configuration under 26918TSD-KIT. |
| Description_ASM | GM GEN V LT4 Engines |
| Description_DEF | Engine Valve Spring Kit |
| Description_DES | 7 Degree Tool Steel Retainer for 8mm Valve, Spring w/ 1.290" O.D |
| Description_DES | Conical .625" Max Lift Valve Spring Kit for GM GEN V LT4 w/ Tool Steel Retainers |
| Description_DES | ID Spring Locator - 1.340" OD, .570" ID, .100" Thickness |
| Description_DES | ID Spring Locator Set of 16 - 1.300" OD, .505" ID, .040" Thickness |
| Description_DES | Machined Steel Set of 16 - 7 Degree, 8mm, Single Groove Race Locks |
| Description_DES | Race Street 1.290" OD Conical Springs; 1.800" Installed Height; 16 Springs |
| Description_DES | Tool Steel Retainer for 7228/7230 Conical Valve Springs |
| Description_INV | Cncl 625 Lft SprngKt LT4 TS Rtnrs |
| Description_KEY | GM, 4.8, 5.3, 5.7, 6.0, 6.2, 7.0, LS1, LS2, LS3, LS4, LS6, LS7, LSA, LS9, Camaro, Silverado, LS Swap, 383, 350, SBC, Chevelle, Yukon, L92, LM7, 325, GMC, Trailblazer, Corvette, GM LS, GEN III, GEN 3, GEN IV, GEN 4, DOD, AFM, VVT, BTR, Texas Speed, LT1, L83, L86, LT4 |
| Description_SHO | Cncl625SprgLT4TS |
| Description_SHP | None |
| height | 2.9 |
| Installed Height | 1.8 |
| length | 11.9 |
| LTL | N |
| Max Lift | 0.625 |
| Number of Springs | 1 |
| Open Load | 410 |
| Retainer Material | Tool Steel |
| Seat Pressure | 136 |
| Spring Rate | 440 |
| Spring Style | Conical |
| Title | Conical .625" Max Lift Valve Spring Kit for GM GEN V LT4 w/ Tool Steel Retainers |
| Valve Spring Series | Conical |
| weight | 3.48 |
| width | 6.4 |
