BD Diesel 1064294B Transmission; 68RFE Transmission; Stage 5; w/Billet Input Shaft;
by BD Diesel
SKU ds_BKJX_1064294B
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Original price
$9,744.95
-
Original price
$9,744.95
Original price
$9,744.95
$9,744.95
$9,744.95
-
$9,744.95
Current price
$9,744.95
Availability:
Out of stock
Description
Transmission; 68RFE Transmission; Stage 5; w/Billet Input Shaft;
Specifications
| Description_DEF | Automatic Transmission Assembly |
| Description_DES | BD 68RFE Transmission Stage 5 - Dodge 2019-2022 4wd c/w Billet Input Shaft |
| Description_DES | Transmission |
| Description_EXT | BD 68RFE Transmission Stage 5 - Dodge 2019-2022 4wd c/w Billet Input Shaft |
| Description_EXT | Transmission; 68RFE Transmission; Stage 5; w/Billet Input Shaft; |
| Description_FAB | BD Deep sump oil pan adds extra fluid and cooling capacity while reducing case flex |
| Description_FAB | BD durable QT100 pressure plates allow for increased clutch counts and reduce deflection and distortion within the clutch drum |
| Description_FAB | BD Durable QT100 Pressure Plates For Increase Clutch Counts |
| Description_FAB | BD Reinforced Accumulator Plate |
| Description_FAB | Custom Big Stack Overdrive Shaft |
| Description_FAB | Custom Bonded Gasket Valve Body |
| Description_FAB | Custom bonded gasket valve body separator plate increases line pressure while stopping internal cross leaks |
| Description_FAB | Hard anodized valve body and new solenoid pack installed in every unit |
| Description_FAB | Heavy Duty Cam & Roller Design Low Reverse One Way Clutch |
| Description_FAB | New 4C Billet Spring Retainer |
| Description_FAB | Over Drive clutches 33% increase & 2C clutches 33% increase |
| Description_FAB | Performance Transmission but with the added touch of a Billet Input Shaft to take the "snap" from rapid throttle and high horsepower |
| Description_FAB | Special tuning required for 2019-up applications for increased line pressure. Line pressure controller not included. |
| Description_FAB | Steel Girdle Added To 2C Piston |
| Description_FAB | Steel girdle added to 2C piston to allow for more clutches and broader apply area |
| Description_FAB | Valve Body And Solenoid Installed In Every Unit |
| Description_INV | TRANS PACKAGE 68RFE DODGE 2019-2022 4WD |
| Description_LAB | Proposition 65 |
| Description_MKT | BD's 68RFE is the industry leading transmission. BD has addressed the common failures associated with the stock 68RFE. Burnt overdrive clutches are a thing of the past, utilizing custom billet QT100 reaction plates, longer "Big Stack" spline OD shaft, and 16 frictional surfaces. Comes with Billet Input Shaft designed to withstand rapid acceleration and high torque. |
| Description_SHO | Auto Trans Assembly |
| Description_SHO | TRANSMISSION STAGE 5 |
| Engine | 6.7L Cummins 19-up |
| height | 27.3 |
| length | 23.5 |
| LTL | N |
| Make | Dodge |
| Prop 65 (C, R or CR) | CR |
| Prop 65 - Short Label | bddiesel_prop65_warning.png |
| Prop 65 Warning | WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| Prop 65 Yes/No | Yes |
| Title | BD 68RFE Transmission Stage 5 - Dodge 2019-2022 4wd c/w Billet Input Shaft |
| Trans Model | Dodge- 68RFE (Auto) 6 Speed |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| weight | 240.0 |
| width | 44.5 |
