BD Diesel 1064292BM Auto Trans Assembly
by BD Diesel
SKU ds_BKJX_1064292BM
Proudly Canadian
Albertan Owned
Supporting Canadian truckers since 2018
Secure Payments
Financing Available
SSL encrypted checkout with financing options
Trusted Brands
Top-Quality Suppliers
Authorized dealer for Fox, Bilstein, BFGoodrich & 50+ brands
Original price
$11,728.00
-
Original price
$11,728.00
Original price
$11,728.00
$11,728.00
$11,728.00
-
$11,728.00
Current price
$11,728.00
Availability:
Out of stock
Description
When you purchase a BD transmission and torque converter package, you are getting a matched set that has been dyno tested together for ultimate performance, and reliability. Every transmission comes with BD's own Heavy Duty pan that adds extra fluid capacity. For towing, street or track, when it comes to a dependable transmission that will stand up to your diesel's power and torque demands, the clear choice is BD.
Specifications
| Description_DEF | Automatic Transmission Assembly |
| Description_DES | BD Dodge 68RFE Trans & Converter Stg 5 Pkg Dodge 2019-2022 2wd c/w Billet Input |
| Description_DES | Transmission Kit |
| Description_EXT | BD Dodge 68RFE Transmission & Converter Package Stage 5 - Dodge 2019-2022 2wd c/w Billet Input Shaft |
| Description_EXT | Transmission Kit; 68RFE Transmission; Stage 5; Incl. Billet Input Shaft/Converter Package; |
| Description_FAB | BD Deep sump oil pan adds extra fluid and cooling capacity while reducing case flex |
| Description_FAB | BD durable QT100 pressure plates allow for increased clutch counts and reduce deflection and distortion within the clutch drum |
| Description_FAB | BD Durable QT100 Pressure Plates For Increase Clutch Counts |
| Description_FAB | BD Reinforced Accumulator Plate |
| Description_FAB | Cast stator designs maximizes torque |
| Description_FAB | Custom Big Stack Overdrive Shaft |
| Description_FAB | Custom Bonded Gasket Valve Body |
| Description_FAB | Custom bonded gasket valve body separator plate increases line pressure while stopping internal cross leaks |
| Description_FAB | Eliminates warpage from clutch heat |
| Description_FAB | Engineered tighter tolerances |
| Description_FAB | Enhanced Stall - Street/Towing applications |
| Description_FAB | Furnaced brazed turbine fins for improved fluid coupling efficiency |
| Description_FAB | Hard anodized valve body and new solenoid pack installed in every unit |
| Description_FAB | HD springs absorb shock of engagement |
| Description_FAB | Heavy Duty Cam & Roller Design Low Reverse One Way Clutch |
| Description_FAB | New 4C Billet Spring Retainer |
| Description_FAB | New sprag components ensure long term durability |
| Description_FAB | Over Drive clutches 33% increase & 2C clutches 33% increase |
| Description_FAB | Reduced overall weight by 12lbs compared to competitors |
| Description_FAB | Riveted piston ensures alignment & eliminates vibration or embrittlement from welding |
| Description_FAB | Self-centering trapezoid teeth design increases contact decreases wear and chatter |
| Description_FAB | Special tuning required for 2019-up applications for increased line pressure. Line pressure controller not included. |
| Description_FAB | Stamp forged 1-piece cover |
| Description_FAB | Steel Girdle Added To 2C Piston |
| Description_FAB | Steel girdle added to 2C piston to allow for more clutches and broader apply area |
| Description_FAB | Taller cover can be rebuilt more often |
| Description_FAB | Thrust bearings - not plastic thrust washers |
| Description_FAB | TORQUE CONVERTOR: |
| Description_FAB | TRANSMISSION: |
| Description_FAB | Trapezoid teeth design |
| Description_FAB | Triple Disc |
| Description_FAB | Valve Body And Solenoid Installed In Every Unit |
| Description_INV | TRANS PACKAGE 68RFE DODGE 2019-2022 2WD |
| Description_LAB | Proposition 65 |
| Description_MKT | When you purchase a BD transmission and torque converter package, you are getting a matched set that has been dyno tested together for ultimate performance, and reliability. Every transmission comes with BD's own Heavy Duty pan that adds extra fluid capacity. For towing, street or track, when it comes to a dependable transmission that will stand up to your diesel's power and torque demands, the clear choice is BD. |
| Description_SHO | Auto Trans Assembly |
| Description_SHO | TRANS PKG STAGE 5 |
| Engine | 6.7L Cummins 19-up |
| height | 27.3 |
| length | 23.5 |
| LTL | N |
| Make | Dodge |
| Prop 65 (C, R or CR) | CR |
| Prop 65 - Short Label | bddiesel_prop65_warning.png |
| Prop 65 Warning | WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| Prop 65 Yes/No | Yes |
| Title | BD Dodge 68RFE Trans & Converter Stg 5 Pkg Dodge 2019-2022 2wd c/w Billet Input |
| Trans Model | Dodge- 68RFE (Auto) 6 Speed |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| weight | 339.0 |
| width | 44.5 |
